Whisper MU-050 Essence PD Wi-Fi Touch Stat - White
Whisper MU-050 Essence PD Wi-Fi Touch Stat - White
SKU : CON0180
Overview
The MU-050 is a versatile PD Programmable Smart Digital Thermostat designed for modern homes and commercial spaces. It combines intuitive app-based control with direct touchscreen operation via five soft-touch icons along the base, presented on a sleek, tempered glass display.In Stock
Couldn't load pickup availability
For warranty information, please refer to the manufacturer’s warranty policy or contact them directly.
Description
Product Part Number
CON0180 - White
CON0181 - Black
Product Overview
The MU-050 is a versatile PD Programmable Smart Digital Thermostat designed for modern homes and commercial spaces. It combines intuitive app-based control with direct touchscreen operation via five soft-touch icons along the base, presented on a sleek, tempered glass display.
Installation is simple and cost-effective, requiring no additional router. The globally recognised Smart Life app ensures fast, plug-and-play setup. The MU-050 integrates seamlessly with smart home ecosystems including Google, Amazon, and Apple, allowing for grouped thermostat control and family-shared app access.
Energy efficiency is built-in via an energy-saving mode, providing manual or timed set-back to reduce heating automatically during periods of vacancy, such as holidays.
The thermostat can function as a room or zone controller, managing electric underfloor heating, zone valves, or connecting to underfloor heating wiring centres. Advanced features include:
- Open window detection
- Icon lock to prevent accidental misuse
- Min/max temperature limits to protect children or vulnerable users
- Highly accurate internal temperature sensor adjustable in 0.5°C increments
- Optional external sensor for overtemperature protection or remote sensing
Weekly programming allows up to 6 cycles per day, with separate schedules for weekdays and weekends, supporting 1-week (5+2), 6+1, or 7-day programming patterns.
Technical Specification
| Feature | Specification |
|---|---|
| Item | 230V Programmable Wi-Fi Thermostat |
| Optional Accessory | Remote sensor probe (10K NTC) |
| Product Codes & Colour Options | PDW1-0050 White, PDW1-0051 Black |
| Material | ABS |
| Mounting | In-wall, 35mm back box |
| Dimensions | 86 × 86 × 48.6 mm |
| Weight | 145 g |
| Power Consumption | <3 W |
| Supply Voltage | 230 V AC |
| Max Switching Output | 16 A |
| Switch Relay Output | 230 V |
| Settable Temperature Range | 5 – 35°C |
| Display Accuracy | 0.5°C |
| Programming Ability | 1 Week (5+2), 6+1, 7-day cycles |
| Connectivity | Wi-Fi 2.4 GHz |
| Protection Rating | IP20 |
| Compliance | UKCA, CE |
| Smart Home Compatibility | Google Assistant, Amazon Alexa, Apple HomeKit |
| Features | Energy-saving mode, open window detection, min/max temperature lock, icon lock, external sensor support |
