• Pipelife 16 x 2mm Natural PE-RT Pipe Coil
1 1

200m COIL OF 16 X 2mm NATURAL PE-RT - Multi 5 Layer

200m COIL OF 16 X 2mm NATURAL PE-RT - Multi 5 Layer

SKU : 3096600050

Overview

QUAL-PE-RT is a high-performance raised-temperature polyethylene pipe designed specifically for underfloor heating (UFH) applications. Its lightweight and highly flexible construction allows for fast, efficient installation with minimal effort, making it an ideal choice for both residential and commercial heating systems.
£170.87 GBP Excl. VAT: £142.39 GBP

In Stock
  • For warranty information, please refer to the manufacturer’s warranty policy or contact them directly.
View full details

Description

Product Part Number

3096600050

Product Overview

QUAL-PE-RT is a high-performance raised-temperature polyethylene pipe designed specifically for underfloor heating (UFH) applications. Its lightweight and highly flexible construction allows for fast, efficient installation with minimal effort, making it an ideal choice for both residential and commercial heating systems.

The pipe features a smooth internal bore, ensuring excellent flow characteristics while reducing pressure loss and minimising the risk of deposits forming within the system. A 5-layer construction with an integrated EVOH oxygen diffusion barrier protects metal components within the heating system from corrosion, guaranteeing long-term, leak-free performance.

Key Features & Benefits

  • Lightweight & Flexible
    PE-RT material bends easily into place, allowing quick installation and tight pipe layouts without the need for special tools.
  • Oxygen Diffusion Barrier
    Integrated EVOH layer prevents oxygen ingress, protecting pumps, manifolds, and other system components from corrosion.
  • Smooth Internal Surface
    Improves water flow efficiency, reduces pressure loss, and limits scale or deposit formation.
  • Long Service Life
    Designed for underfloor heating and radiator integration systems with a guaranteed lifespan of up to 50 years.
  • Reliable & Leak-Free
    Multi-layer construction ensures durability, strength, and long-term system integrity.

Technical Specification

Feature Specification
Pipe Type PE-RT Raised Temperature Barrier Pipe
Construction 5-layer with EVOH oxygen barrier
Outside Diameter 16 mm
Wall Thickness 2 mm
Coil Length 200 m
Material PE-RT
Oxygen Barrier Standard ISO 17455
Manufacturing Standard ISO 22391
Application Classes ISO 10508 – Class 4 & 5 (UFH & radiator integration)
Maximum Service Temperature 70 °C
Maximum Working Pressure 6 bar
Colour Natural / as supplied

Frequently Asked Questions

  • What’s the difference between multi-layer and PEX underfloor heating pipe?

    PEX pipe is flexible and widely used for underfloor heating, while multi-layer pipe incorporates additional layers that can improve shape retention and reduce thermal expansion. The correct option depends on the system design and compatible fittings.

  • How much underfloor heating pipe do I need for my floor area?

    Pipe quantity depends on the heated floor area, pipe spacing, number of loops and maximum suitable loop length. A designed UFH layout provides a more accurate quantity than calculating from floor area alone.

  • What underfloor heating pipe spacing should I use?

    Pipe spacing should be determined by the room’s heat loss and required heat output rather than room type alone. Areas with higher heating demand may require closer pipe spacing.
